Drone Electricity Inspection Application Scenarios
——

- Grid lines are intricate, inspection links, a variety of problems in the event of a failure is difficult to determine the first time - The economic losses caused by the fault investigation time is positively correlated to the normal operation of the residents of the production and life of great impact - Traditional monitoring equipment has blind spots, limited observation range and angle. - Traditional monitoring, data collected, independent of each other, not related to each other, it is difficult for managers to make systematic, global judgement.

  • Zhejiang Power Distribution Grid
  • Shanghai Qingpu Power Grid
  • Beijing High Voltage Grid

   Zhejiang Distribution Grid Inspection


     - The distribution network of a local power supply office in Zhejiang is

      deployed along a route of 224.99 km, through mountainous areas and

      villages and towns.


    - Due to the large number of equipment, small spacing and complex system structure

      of the distribution network system, manual inspection is difficult, coupled with the

      variable terrain, which invariably increases the workload of inspectors


    - Due to the uniqueness of distribution network overhead lines, many drones are

      susceptible to GPS signal interference when flying at low altitude, and the flight

      safety of drones is not guaranteed.


    - The endurance of the drone itself is not enough to support its inspection of the

      entire area, and it can only rely on inspectors to manually replace the battery

      and change the location to achieve full coverage of the inspection area.

   Shanghai Qingpu Grid Inspection


     - The introduction of AI inspection system and more than ten sets of micro-docking station

        in Qingpu District, Shanghai, has brought about a qualitative leap in the efficiency

        of power grid inspection in the region.


    - Using the "AI" algorithm of automatic deviation correction technology, the target point is accurately

      photographed, and problems such as self-detonation, breakage, filth, tilt, falling off of pressure plate,

      rusting of bolts, missing pins, rusting of cross-arms,

      tilting of cross-arms, etc. of the insulator can be accurately identified.


    - Transmit to the background to provide decision -making basis for the management personnel,

      automatic analysis, precise research and accurate report on the location of the target point,

      the operation and maintenance personnel can go directly to the scene, to minimise

      the loss caused by power supply interruption.

   Beijing High Voltage Grid Inspection


    - Transmission voltage is usually high, giving inspectors a great security risk, such as if

       the transmission grid is shut down and the normal life of the residents caused by impacts


    - The manager can assign the drone to perform the task after presetting the route on the platform,

      and the drone will take off from the docking station to patrol around the pole tower after receiving

      the instruction to achieve automatic take-off and automatic cruise,

      and then push the video stream to the backstage screen of the management centre

      through the on-site ground station by the 4G/5G or wired network,

      so as to browse the video data of visible light task collected by the drone

      for inspection in real time. Visible mission video data collected by the drone patrol


    - Accurately analyse the target object using massive data (including defective sample data),

      combine feature extraction data with semantic and contextual information,

      and deep learning combined with traditional image algorithms to provide homogeneous,

      efficient and intelligent inspection services for the transmission grid.







Can formulate urban area flight missions, command and dispatch drones, and autonomously complete drone inspection missions
Docking station comprehensively covers the urban inspection area, with 7*24 hours standby, providing high-frequency drone mobilisation capability
The drone can mount a 30x optical zoom camera and an infrared camera at the same time, and the high-definition camera shoots at high altitude to obtain real-time images.
Accurate photography of the target point, for insulators can be accurately identified for self-explosion, broken, dirty, tilted, pressure plate off and bolt corrosion, missing pins, rusted cross-arms, tilted cross-arms and other problems.
